Kabelbaum Husqvarna Automower 220AC/230ACX – 5010037-03
Tested used part (12-month warranty): Genuine Husqvarna wiring harness / wiring assy for selected Automower® 200-series models.
Cosmetic grades: A = like new/minor signs of use, B = visible signs of use, technically perfect.
- Manufacturer no./MPN: 5010037-03 (501003703)
- EAN/GTIN: 7391883236017
- Replaces (among others): 5010037
Installation note: The mower must be opened for installation. To ensure water tightness, the seal strips should be replaced.
Variant note: For 220AC / Solar Hybrid with small wheel-motor plugs (black motor flange), you need harness 5010037-02.
Compatibility
| Model | Years (approx.) | Note |
|---|---|---|
| Husqvarna Automower 220AC | 2007–2015 | Generation G2 / Platform 1 (model dependent) |
| Husqvarna Automower 230ACX | 2007–2014 | incl. versions with Dunker wheel motors |
| Husqvarna Automower Solar Hybrid | 2008–2012 | version dependent (check connectors) |
| Husqvarna Automower Solar Hybrid Black Metallic Edition | 2013–2015 | version dependent |
| Gardena R160 | 2013–2015 | Generation G2 |
Tip: Please compare connectors and part numbers before purchase.
nn• Genuine Husqvarna wiring harness (MPN 5010037-03 / 501003703).n• Fits Automower 220AC & 230ACX; Solar Hybrid & Gardena R160 depending on version.n• Replaces, among others, Husqvarna part no. 5010037.n• Installation requires opening the mower – replace seal strips to maintain water tightness.n• Shipping weight approx. 0.13 kg (≈130 g).nn
