Front joystick kit (lift sensor) for Husqvarna Automower – 581620903
Used and tested front joystick/lift-sensor kit for the floating top cover. Helpful for faults like “collision sensor problem”, “collision active” or “lifted”.
- MPN: 581620903 (Husqvarna part no. 5816209-03)
- Replaces: 5816209-01, 5816209-02 (incl. 581620901, 581620902)
- Front holder for the cover; carries the sensor mechanism
- Shipping weight (source): 0.19 kg
- Used part, inspected and function-tested
Tech
- Part: front joystick kit / holder for lift sensor and cover
- Function: centers the cover; triggers sensors for collision/lift detection
- Compatible brands: Husqvarna, Gardena
Installation
Installation requires opening the mower. Replace seals/sealing strips to keep the mower watertight.
If the cover is not centered, check the rubber bellows and joystick mechanism for dirt or cracks.
- Match the MPN before ordering
- Replace seals when opening
- Check symptom: “collision sensor…”, “collision active”, “lifted”
Compatibility
| Model | Matching part numbers/MPN | Replaces (verified) | Note/version |
|---|
- Husqvarna Automower 310 – 2015->
- Husqvarna Automower 315 – 2015->
- Husqvarna Automower 315X – 2018->
- Husqvarna Automower 320 – 2013-2015
- Husqvarna Automower 330X – 2013-2015
- Husqvarna Automower 420 – 2016->
- Husqvarna Automower 430X – 2016->
- Husqvarna Automower 435X AWD – —
- Husqvarna Automower 440 – 2017->
- Husqvarna Automower 450X – 2016->
- Husqvarna Automower 520 – 2018->
- Husqvarna Automower 535X AWD – —
- Husqvarna Automower 540 – —
- Husqvarna Automower 550 – 2018->
- Husqvarna Automower 550X – —
- Gardena SILENO R100Li – 2016->
- Gardena SILENO R100LiC – 2016->
- Gardena SILENO+ R130Li – 2016->
- Gardena SILENO+ R130LiC – 2016->
- Gardena SILENO+ R160Li – 2016->
| 581620903, 5816209-03, 581 62 09-03, 581 62 09 03, 9000499 | 5816209-01, 5816209-02, 581620901, 581620902 | Front joystick kit (lift sensor); for collision faults, inspect joystick and bellows |
Important: Versions may differ by model year. Always verify the MPN/part number on your mower or parts list.
• Front joystick / cover holder for the floating top cover
• Check when you see “collision sensor” or “lifted” style errors
• MPN 581620903 / Husqv. 5816209-03; replaces 5816209-01/-02
• Shipping weight (source): 0.19 kg
• Used & tested part
